Digital Load Cell

Digital Load Cell
Digital Load Cell
Product Code : PI-01
Brand Name : PRABHAT INDIA
Product Description
We are a well-known Manufacturer, Supplier and Service Provider of Digital Load Cell, which are made by using the premium quality components. The offered range is an analog to digital converter mounted on the load cell. The offered products capable of transmitting the weight from the platform in digital form, as they are multi step calibrated load cells. Furthermore, our company is offering the range of Digital Load Cell at competitive price.

Features :
  • Cost Effective
  • Better Performance & Protection.
  • Easy field replace-ability.
  • Long Distance between weighbridge room and structure (up to 500 mt).
  • Higher Accuracy.
  • No Calibration required.
  • Very simple & easy installation procedure.
  • No Corner error.
Application :
  • Large Scales
  • Tank Scales
  • Weighbridge

Technical Specification :

Rated Load

30T

Safe Overload

150% FS

Rated Output

30000 Div

Combined Error

0.02% FS

Creep Error

0.02% FS

Zero Balance

0.1% FS

Temperature Range

-30C~+70C

A/D Module Resolution

200000

Data Refresh Rate

50 Hz

Input Voltage

9~12V DC

Max Input Voltage

20V DC

Baud Rate

9600 BPS

Signal Trans. Distance

500 M

Protection Class

IP 68
