Analog Load Cell

Analog Load Cell
Analog Load Cell
Product Code : PI-02
Brand Name : PRABHAT INDIA
Product Description
The range of Analog Load Cell is manufactured on our premises under the guidance of our experienced professionals. All the products are made by using high quality strain gauges and special alloy steel. The offered Load cells are supported by strong technical team. All the precious patrons can avail the benefit of the range of Analog Load Cell at market leading prices.

Features
  • Cost Effective.
  • Cup ball mechanism for very easy installation & maintenance.
  • Current calibrated for precision output.
  • Easy field replaceability.
  • Galvanized Bottom prevents Rusting
  • Higher Accuracy
  • Minimal corner error.
  • Appear cleaner in looks compared to other load cells.
  • High strength cable with better finish
  • Twelve months Warranty from the date of dispatch

Technical Specification :

Sensitivity

2.00 + 0.002 mV/V

Error Class

C2

Creep (30 Minutes)

+0.02% FS

Zero Balance

1% FS

TC Zero

+0.02% FS/10 C

TC Span

+0.02% FS/10 C

Input Resistance

750+10Ω

Output Resistance

750+3Ω

Insulation Resistance

5000MWΩ

Maximum Safe Over Load

150%FS

Ultimate Over Load

300%FS

Excitation Recommended

10~12V DC

Excitation Maximum

15V DC

Protection Class

IP68

Construction

Alloy Steel

Cable Length

12M
